دیتاشیت LP3855ET-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP3855-ADJ |
|---|---|
| حجم فایل | 2695.225 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت LP3855-ADJ |
LP3855-ADJ Datasheet |
|---|
مشخصات
- RoHS: true
- Feature: Overcurrent Protection;Thermal Protection
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP3855ET-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 1.5A
- Output Voltage: 1.23V~6.6V
- Dropout Voltage: 0.435V@(1.5A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 7V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 3mA
- Power Supply Rejection Ratio (PSRR): 73dB@(120Hz)
- Package: TO-220-5
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.435V @ 1.5A
- Current - Supply (Max): 10mA
- Current - Output: 1.5A
- Current - Quiescent (Iq): 3mA
- Voltage - Input (Max): 7V
- Base Part Number: LP3855
- Package / Case: TO-220-5 Formed Leads
- Voltage - Output (Max): 6.6V
- Output Configuration: Positive
- Series: -
- Supplier Device Package: TO-220-5
- PSRR: 73dB ~ 57dB (120Hz)
- Part Status: Active
- Mounting Type: Through Hole
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Output (Min/Fixed): 1.23V
- Number of Regulators: 1
- Packaging: Tube
- detail: Linear Voltage Regulator IC 1 Output 1.5A TO-220-5
