ADS124S06, ADS124S08 Datasheet دیتاشیت

ADS124S06, ADS124S08 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADS124S06, ADS124S08 Datasheet
حجم فایل 3625.545 کیلوبایت
نوع فایل pdf
تعداد صفحات 113

مشاهده دیتاشیت ADS124S06, ADS124S08 Datasheet-Isee

دانلود دیتاشیت

سایر مستندات

ADS124S08IPBSR 114 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS124S06IRHBR
  • Package: QFN-32-EP(5x5)
  • Manufacturer: Texas Instruments
  • Configuration: MUX-PGA-ADC
  • Voltage - Supply, Analog: 2.7V ~ 5.25V
  • Base Part Number: ADS124
  • Operating Temperature: -50°C ~ 125°C
  • Voltage - Supply, Digital: 2.7V ~ 3.6V
  • Number of Bits: 24
  • Series: -
  • Package / Case: 32-VFQFN Exposed Pad
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 32-VQFN (5x5)
  • Number of Inputs: 6
  • Ratio - S/H:ADC: 0:1
  • Reference Type: External, Internal
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 4k
  • Number of A/D Converters: 1
  • Data Interface: SPI
  • Architecture: Sigma-Delta
  • Input Type: Single Ended
  • Features: PGA
  • detail: 24 Bit Analog to Digital Converter 6 Input 1 Sigma-Delta 32-VQFN (5x5)
