دیتاشیت AD8224BCPZ-R7

AD8224

مشخصات دیتاشیت

نام دیتاشیت AD8224
حجم فایل 753.691 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت AD8224

AD8224 Datasheet

مشخصات

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Instrumentation OpAmps
  • Datasheet: Analog Devices AD8224BCPZ-R7
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: 1.5MHz
  • Number of Circuits: 2
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 10pA
  • Gain Bandwidth Product(GBP): -
  • Voltage - Input Offset(Vos): 175uV
  • Package: LFCSP-16
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: Instrumentation
  • Output Type: Rail-to-Rail
  • Slew Rate: 2V/µs
  • Current - Input Bias: 10pA
  • Voltage - Input Offset: 175µV
  • Current - Supply: 750µA
  • Current - Output / Channel: 15mA
  • Voltage - Supply, Single/Dual (±): 4.5V ~ 36V, ±2.25V ~ 18V
  • Mounting Type: Surface Mount
  • Package / Case: 16-VQFN Exposed Pad, CSP
  • Supplier Device Package: 16-LFCSP-VQ (4x4)
  • Base Part Number: AD8224
  • detail: Instrumentation Amplifier 2 Circuit Rail-to-Rail 16-LFCSP-VQ (4x4)
