دیتاشیت AD5421BREZ-REEL7

AD5421

مشخصات دیتاشیت

نام دیتاشیت AD5421
حجم فایل 822.557 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت AD5421

AD5421 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5421BREZ-REEL7
  • Package: HTSSOP-28-EP-4.5mm
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 1
  • Settling Time: 50µs (Typ)
  • Output Type: Voltage - Unbuffered
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 1.71V ~ 5.5V
  • Voltage - Supply, Digital: 3.17V ~ 3.48V
  • INL/DNL (LSB): -, ±1 (Max)
  • Architecture: Cyclic Serial
  • Operating Temperature: -40°C ~ 105°C
  • Package / Case: 28-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Supplier Device Package: 28-TSSOP-EP
  • Mounting Type: Surface Mount
  • Base Part Number: AD5421
  • detail: 16 Bit Digital to Analog Converter 1 28-TSSOP-EP
