SN74LS646DW دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LS646DW |
|---|---|
| حجم فایل | 81.412 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت SN74LS646DW |
دانلود دیتاشیت |
|---|
سایر مستندات
SN54LS846-649, SN74LS646-649 13 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LS646DW
- output type: Tri-State
- Logic Family: 74LS
- Sink Current: 24mA
- Source Current: 15mA
- Supply Voltage: 4.75V~5.25V
- Number of Elements: 1
- Operating Temperature: 0°C~+70°C
- Number of Bits per Element: 8
- Package: SOP-24-300mil
- Manufacturer: Texas Instruments
- Series: 74LS
- Package / Case: 24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 24-SOIC
- Part Status: Active
- Current - Output High, Low: 15mA, 24mA
- Mounting Type: Surface Mount
- Base Part Number: SN74LS64
- Voltage - Supply: 4.75V ~ 5.25V
- Packaging: Tube
- Input Type: -
- Logic Type: Transceiver, Non-Inverting
- detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output 24-SOIC
