دیتاشیت AD9268BCPZ-125
مشخصات دیتاشیت
| نام دیتاشیت |
AD9268
|
| حجم فایل |
2340.456
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
44
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices AD9268BCPZ-125
-
Interface:
Parallel
-
resolution:
16Bit
-
Supply Voltage:
1.7V~1.9V
-
differential input:
Yes
-
number of channels:
2
-
sampling frequency:
125MHz
-
Operating Temperature:
-40°C~+85°C
-
Package:
LFCSP-64-VQ
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Number of Bits:
16
-
Sampling Rate (Per Second):
125M
-
Number of Inputs:
2
-
Input Type:
Differential
-
Data Interface:
LVDS - Parallel, Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
2
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
1.7V ~ 1.9V
-
Voltage - Supply, Digital:
1.7V ~ 1.9V
-
Features:
Simultaneous Sampling
-
Package / Case:
64-VFQFN Exposed Pad, CSP
-
Supplier Device Package:
64-LFCSP-VQ (9x9)
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD9268
-
detail:
16 Bit Analog to Digital Converter 2 Input 2 Pipelined 64-LFCSP-VQ (9x9)
