ADS7279IPW دیتاشیت

ADS7279IPW

مشخصات دیتاشیت

نام دیتاشیت ADS7279IPW
حجم فایل 62.824 کیلوبایت
نوع فایل pdf
تعداد صفحات 52

دانلود دیتاشیت ADS7279IPW

دانلود دیتاشیت

سایر مستندات

ADS7279,80 51 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS7280IPWR
  • Interface: SPI;DSP
  • resolution: 14
  • Supply Voltage: 5V
  • number of channels: 2
  • sampling frequency: 1MHz
  • Operating Temperature: -40°C~+85°C
  • Package: TSSOP-16
  • Manufacturer: Texas Instruments
  • Configuration: MUX-S/H-ADC
  • Voltage - Supply, Analog: 5V
  • Base Part Number: ADS7280
  • Voltage - Supply, Digital: 1.65V ~ 5.5V
  • Number of Bits: 14
  • Series: -
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Packaging: Tape & Reel (TR)
  • Supplier Device Package: 16-TSSOP
  • Number of Inputs: 2
  • Ratio - S/H:ADC: 1:1
  • Reference Type: External
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 1M
  • Number of A/D Converters: 1
  • Data Interface: SPI, DSP
  • Architecture: SAR
  • Input Type: Pseudo-Differential, Single Ended
  • Features: -
  • detail: 14 Bit Analog to Digital Converter 2 Input 1 SAR 16-TSSOP
