ADA4891-2ARZ Datasheet

ADA4891-2ARZ

Datasheet specifications

Datasheet's name ADA4891-2ARZ
File size 104.145 KB
File type pdf
Number of pages 24

Download Datasheet ADA4891-2ARZ

Download Datasheet

Other documentations

ADA4891-(1-4) 24 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Analog Devices ADA4891-2WARMZ-R7
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: 90MHz
  • Output Current: 125mA
  • Operating Temperature: -40°C~+125°C
  • Current - Input Bias(Ib): 2pA
  • Gain Bandwidth Product(GBP): 105MHz
  • Package: MSOP-8
  • Manufacturer: Analog Devices
  • Series: Automotive
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Amplifier Type: General Purpose
  • Number of Circuits: 2
  • Output Type: Rail-to-Rail
  • Slew Rate: 210V/µs
  • Current - Input Bias: 2pA
  • Voltage - Input Offset: 2.5mV
  • Current - Supply: 4.4mA
  • Current - Output / Channel: 125mA
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 5.5V, ±1.35V ~ 2.75V
  • Mounting Type: Surface Mount
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Base Part Number: ADA4891
  • detail: General Purpose Amplifier 2 Circuit Rail-to-Rail 8-MSOP
