- دیتاشیت AD7904BRUZ-REEL7
AD7904BRUZ-REEL7 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AD7904BRUZ-REEL7 |
|---|---|
| حجم فایل | 538.401 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت AD7904BRUZ-REEL7 |
دانلود دیتاشیت |
|---|
سایر مستندات
AD7904,14,24 32 pages
AD7914BRUZ-REEL7 32 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices AD7904BRUZ-REEL7
- Interface: SPI;DSP
- resolution: 8Bit
- Supply Voltage: 2.7V~5.25V
- number of channels: 4
- sampling frequency: 1MHz
- Operating Temperature: -40°C~+85°C
- Package: TSSOP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of Bits: 8
- Sampling Rate (Per Second): 1M
- Number of Inputs: 4
- Input Type: Single Ended
- Data Interface: SPI, DSP
- Configuration: MUX-S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: External
- Voltage - Supply, Analog: 2.7V ~ 5.25V
- Voltage - Supply, Digital: 2.7V ~ 5.25V
- Features: -
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Mounting Type: Surface Mount
- Base Part Number: AD7904
- detail: 8 Bit Analog to Digital Converter 4 Input 1 SAR 16-TSSOP
