- دیتاشیت SN74ALS639AN
SN74ALS639AN دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74ALS639AN |
|---|---|
| حجم فایل | 62.057 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت SN74ALS639AN |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74ALS638A/39A, SN74AS638A/639 13 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74ALS639AN
- Input type: -
- output type: Open Collector
- Logic Family: 74ALS
- Sink Current: 24mA
- Source Current: -;15mA
- Supply Voltage: 4.5V~5.5V
- Number of Elements: 1
- Operating Temperature: 0°C~+70°C
- Number of Bits per Element: 8
- Package: PDIP-20
- Manufacturer: Texas Instruments
- Series: 74ALS
- Package / Case: 20-DIP (0.300", 7.62mm)
- Supplier Device Package: 20-PDIP
- Part Status: Active
- Current - Output High, Low: -, 24mA; 15mA, 24mA
- Mounting Type: Through Hole
- Base Part Number: SN74ALS6
- Voltage - Supply: 4.5V ~ 5.5V
- Packaging: Tube
- Logic Type: Transceiver, Non-Inverting
- detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element Open Collector, Push-Pull Output 20-PDIP
