دیتاشیت ADUM3160WBRWZ
مشخصات دیتاشیت
| نام دیتاشیت |
ADUM3160
|
| حجم فایل |
289.88
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
Automotive
-
Packaging:
Tube
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
USB
-
Isolated Power:
No
-
Number of Channels:
2
-
Inputs - Side 1/Side 2:
2/2
-
Channel Type:
Bidirectional
-
Voltage - Isolation:
2500Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Data Rate:
12Mbps
-
Propagation Delay tpLH / tpHL (Max):
70ns, 70ns
-
Pulse Width Distortion (Max):
-
-
Rise / Fall Time (Typ):
20ns, 20ns (Max)
-
Voltage - Supply:
3V ~ 5.5V
-
Operating Temperature:
-40°C ~ 105°C
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Supplier Device Package:
16-SOIC
-
Base Part Number:
ADUM3160
-
detail:
USB Digital Isolator 2500Vrms 2 Channel 12Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
