ADG528AKPZ Datasheet
Datasheet specifications
| Datasheet's name | ADG528AKPZ |
|---|---|
| File size | 162.05 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet ADG528AKPZ |
Download Datasheet |
|---|
Other documentations
ADG528A,529A 13 pages
ADG528ATQ 13 pages
Technical specifications
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG528AKPZ
- Turn-on time: 300ns
- Turn-off time: 300ns
- Supply Voltage: 10.8V~16.5V
- Number of Channels: 1
- On-State Resistance (Max): 450Ω
- Package: PLCC-20
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Switch Circuit: -
- Multiplexer/Demultiplexer Circuit: 8:1
- Number of Circuits: 1
- Channel-to-Channel Matching (ΔRon): 22.5Ohm
- Voltage - Supply, Single (V+): 10.8V ~ 16.5V
- Voltage - Supply, Dual (V±): ±10.8V ~ 16.5V
- Switch Time (Ton, Toff) (Max): 300ns, 300ns
- -3db Bandwidth: -
- Charge Injection: 4pC
- Channel Capacitance (CS(off), CD(off)): 5pF, 22pF
- Current - Leakage (IS(off)) (Max): 1nA
- Crosstalk: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 20-LCC (J-Lead)
- Supplier Device Package: 20-PLCC (9x9)
- Base Part Number: ADG528
- detail: 1 Circuit IC Switch 8:1 450Ohm 20-PLCC (9x9)
