SN74ALS29821DW دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN74ALS29821DW
|
|
حجم فایل
|
83.634
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
D-Type
-
Series:
74ALS
-
Category:
Logic ICs/Flip Flops
-
Function:
Standard
-
Datasheet:
Texas Instruments SN74ALS29821DW
-
Output Type:
Tri-State;Non-Inverted
-
Sink Current:
48mA
-
Trigger Type:
上升沿
-
Source Current:
24mA
-
Supply Voltage:
4.75V~5.25V
-
Clock Frequency:
-
-
Input Capacitance:
-
-
Number of Elements:
1
-
Operating Temperature:
0°C~+70°C
-
Quiescent Current (Iq):
115mA
-
Maximum Propagation Delay:
16ns@5V,300pF
-
Number of Bits per Element:
10
-
Package:
SOP-24-300mil
-
Manufacturer:
Texas Instruments
-
Package / Case:
24-SOIC (0.295", 7.50mm Width)
-
Current - Output High, Low:
24mA, 48mA
-
Current - Quiescent (Iq):
115mA
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Max Propagation Delay @ V, Max CL:
16ns @ 5V, 300pF
-
Voltage - Supply:
4.75V ~ 5.25V
-
Packaging:
Tube
-
Base Part Number:
SN74ALS2
-
Supplier Device Package:
20-SOIC
-
detail:
Flip Flop 1 Element D-Type 10 Bit Positive Edge 24-SOIC (0.295", 7.50mm Width)
