- دیتاشیت MSP430F168IPMR
MSP430F168IPMR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MSP430F168IPMR |
|---|---|
| حجم فایل | 122.579 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 80 |
دانلود دیتاشیت MSP430F168IPMR |
دانلود دیتاشیت |
|---|
سایر مستندات
MSP430F15x,16x,161x 80 pages
مشخصات فنی
- RoHS: true
- CPU Core: MSP430
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: Texas Instruments MSP430F168IPMR
- CPU Maximum Speed: 8MHz
- GPIO Ports Number: 48
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Direct Memory Access: Yes
- Program Storage Size: 48KB
- Operating Voltage Range: 1.8V~3.6V
- Operating Temperature Range: -40°C~+85°C
- Package: TQFP-64(10x10)
- Manufacturer: Texas Instruments
- Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Base Part Number: 430F168
- Speed: 8MHz
- Package / Case: 64-LQFP
- Program Memory Type: FLASH
- EEPROM Size: -
- Supplier Device Package: 64-LQFP (10x10)
- Series: MSP430x1xx
- Operating Temperature: -40°C ~ 85°C (TA)
- Number of I/O: 48
- Oscillator Type: Internal
- RAM Size: 2K x 8
- Part Status: Active
- Mounting Type: Surface Mount
- Core Size: 16-Bit
- Connectivity: I²C, SPI, UART/USART
- Program Memory Size: 48KB (48K x 8 + 256B)
- Core Processor: MSP430
- Packaging: Tape & Reel (TR)
- Data Converters: A/D 8x12b; D/A 2x12b
- detail: MSP430 MSP430x1xx Microcontroller IC 16-Bit 8MHz 48KB (48K x 8 + 256B) FLASH 64-LQFP (10x10)
