دیتاشیت DAC7615UB/1K

DAC7615

مشخصات دیتاشیت

نام دیتاشیت DAC7615
حجم فایل 511.896 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت DAC7615

DAC7615 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC7615UB/1K
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 10us
  • Supply Voltage: 5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SOP-16-300mil
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage - Supply, Digital: 5V
  • Voltage - Supply, Analog: ±5V
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Supplier Device Package: 16-SOIC
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Number of Bits: 12
  • Differential Output: No
  • Part Status: Active
  • Reference Type: External
  • Mounting Type: Surface Mount
  • Architecture: R-2R
  • Number of D/A Converters: 4
  • Packaging: Tape & Reel (TR)
  • Base Part Number: DAC7615
  • Data Interface: SPI
  • detail: 12 Bit Digital to Analog Converter 4 16-SOIC
