دیتاشیت ADS7862YB/250
مشخصات دیتاشیت
| نام دیتاشیت | ADS7862 Datasheet |
|---|---|
| حجم فایل | 973.462 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت ADS7862 Datasheet |
ADS7862 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Texas Instruments ADS7862YB/250
- Interface: SPI
- resolution: 12Bit
- Supply Voltage: 5V
- differential input: Yes
- number of channels: 4
- sampling frequency: 500kHz
- Operating Temperature: -40°C~+85°C
- Package: TQFP-32(5x5)
- Manufacturer: Texas Instruments
- Configuration: MUX-S/H-ADC
- Voltage - Supply, Analog: 5V
- Base Part Number: ADS7862
- Voltage - Supply, Digital: 5V
- Number of Bits: 12
- Series: -
- Package / Case: 32-TQFP
- Packaging: Cut Tape (CT)
- Supplier Device Package: 32-TQFP (5x5)
- Number of Inputs: 4
- Ratio - S/H:ADC: 1:1
- Reference Type: External, Internal
- Mounting Type: Surface Mount
- Part Status: Discontinued at Digi-Key
- Sampling Rate (Per Second): 500k
- Number of A/D Converters: 2
- Data Interface: SPI
- Architecture: SAR
- Input Type: Differential
- Features: Selectable Address, Simultaneous Sampling
- detail: 12 Bit Analog to Digital Converter 4 Input 2 SAR 32-TQFP (5x5)
