دیتاشیت UC285-x, 385-x

UC285-x, 385-x

مشخصات دیتاشیت

نام دیتاشیت UC285-x, 385-x
حجم فایل 264.302 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

UC285-x, 385-x

دانلود دیتاشیت

سایر مستندات

UC285-1/2/3/ADJ, UC385-1/2/3/ADJ 18 pages

UC285TDKTTT-ADJ 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments UC385T-3
  • Output Current: 5A
  • Output Voltage: 2.5V
  • Dropout Voltage: 2.1V@(5A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 7.5V
  • Operating Temperature: 0°C~+100°C
  • Package: TO-220-5
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage Dropout (Max): 2.1V @ 5A
  • Package / Case: TO-220-5
  • Base Part Number: UC385
  • Supplier Device Package: TO-220-5
  • Current - Output: 5A
  • PSRR: -
  • Part Status: Active
  • Voltage - Input (Max): 7.5V
  • Mounting Type: Through Hole
  • Control Features: -
  • Protection Features: Over Temperature, Reverse Polarity, Short Circuit
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): -
  • Packaging: Tube
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Output Type: Fixed
  • detail: Linear Voltage Regulator IC 1 Output 5A TO-220-5
