دیتاشیت LM293H/NOPB

مشخصات دیتاشیت

دانلود دیتاشیت LM193,293,393,2903 Datasheet	LM193,293,393,2903 Datasheet Datasheet

RoHS: true
Category: Operational Amplifier/Comparator/Comparators
Datasheet: Texas Instruments LM293H/NOPB
Output Type: 开集;轨到轨
Supply Voltage: 2V~36V;1V~18V
Number of Elements: -
Operating Temperature: -25°C~+85°C
Input Bias Current (Ib): 0.25uA
Input Offset Voltage (Vos): 5mV
Input Hysteresis Voltage (Vhys): -
Common Mode Rejection Ratio (CMRR): -
Package: TO-99
Manufacturer: Texas Instruments
Series: -
Type: General Purpose
Package / Case: TO-205AA, TO-5-8 Metal Can
Voltage - Input Offset (Max): 5mV @ 30V
Current - Output (Typ): 16mA @ 5V
Part Status: Active
Base Part Number: LM293
Mounting Type: Through Hole
Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
Propagation Delay (Max): 700ns
Current - Input Bias (Max): 0.25µA @ 5V
Hysteresis: -
Packaging: Box
CMRR, PSRR (Typ): -
Current - Quiescent (Max): 2.5mA
Supplier Device Package: TO-5-8
detail: Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL TO-5-8
