DCR011205UG4 دیتاشیت

DCR01

مشخصات دیتاشیت

نام دیتاشیت DCR01
حجم فایل 822.505 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت DCR01

دانلود دیتاشیت

سایر مستندات

مستندات دیگری یافت نشد!

مشخصات فنی

  • Type: Isolated Module
  • Voltage - Output 3: -
  • Number of Outputs: 1
  • Voltage - Output 2: -
  • Voltage - Input (Max): 13.2V
  • Base Part Number: DCR011205
  • Size / Dimension: 0.70" L x 0.41" W x 0.10" H (17.9mm x 10.3mm x 2.5mm)
  • Applications: ITE (Commercial)
  • Power (Watts): 1W
  • Package / Case: 28-SOIC (0.295", 7.50mm Width), 12 Leads
  • Efficiency: -
  • Current - Output (Max): 200mA
  • Supplier Device Package: 12-SOP
  • Series: DCR01 (1W)
  • Operating Temperature: -40°C ~ 85°C
  • Voltage - Input (Min): 10.8V
  • Voltage - Isolation: 1kV
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Control Features: Enable, Active High
  • Voltage - Output 1: 5V
  • Manufacturer: Texas Instruments
  • Packaging: Tube
  • Features: Remote On/Off, OTP, SCP
  • detail: Isolated Module DC DC Converter 1 Output 5V 200mA 10.8V - 13.2V Input
