ADUM5212CRSZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADUM5212CRSZ
|
|
حجم فایل
|
100.769
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
23
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Digital Isolators
-
Datasheet:
Analog Devices ADUM5212CRSZ
-
Applications:
-
-
Isolation Technology:
-
-
Voltage Isolation or Not:
-
-
Package:
SSOP-20-5.2mm
-
Manufacturer:
Analog Devices
-
Series:
IsoPower®, iCoupler®
-
Packaging:
Tube
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
General Purpose
-
Isolated Power:
Yes
-
Number of Channels:
2
-
Inputs - Side 1/Side 2:
0/2
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
2500Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Data Rate:
100Mbps
-
Propagation Delay tpLH / tpHL (Max):
24ns, 24ns
-
Pulse Width Distortion (Max):
2ns
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Voltage - Supply:
2.7V ~ 5.5V
-
Operating Temperature:
-40°C ~ 105°C
-
Mounting Type:
Surface Mount
-
Package / Case:
20-SSOP (0.209", 5.30mm Width)
-
Supplier Device Package:
20-SSOP
-
Base Part Number:
ADUM5212
-
detail:
General Purpose Digital Isolator 2500Vrms 2 Channel 100Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
