ADP3334ARZ-REEL7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADP3334ARZ-REEL7
|
|
حجم فایل
|
83.252
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
11
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices ADP3334ARZ-REEL7
-
Output Type:
Adjustable
-
Output Current:
500mA
-
Output Voltage:
1.5V~10V
-
Dropout Voltage:
0.4V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
11V
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Quiescent Current (Ground Current):
130uA
-
Package:
SOIC-8
-
Manufacturer:
Analog Devices
-
Series:
anyCAP®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
11V
-
Voltage - Output (Min/Fixed):
1.5V
-
Voltage - Output (Max):
10V
-
Voltage Dropout (Max):
0.4V @ 500mA
-
Current - Output:
500mA
-
Current - Quiescent (Iq):
130µA
-
Current - Supply (Max):
10mA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
ADP3334
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 8-SOIC
