ADS8578S Datasheet دیتاشیت

ADS8578S Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADS8578S Datasheet
حجم فایل 2461.52 کیلوبایت
نوع فایل pdf
تعداد صفحات 61

مشاهده دیتاشیت ADS8578S Datasheet

دانلود دیتاشیت

سایر مستندات

ADS8578SIPMR 59 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS8578SIPMR
  • Interface: Parallel;serial
  • resolution: 14Bit
  • Supply Voltage: 4.75V~5.25V
  • number of channels: 8
  • sampling frequency: 200kHz
  • Operating Temperature: -40°C~+125°C
  • Package: LQFP-64(10x10)
  • Manufacturer: Texas Instruments
  • Configuration: PGA-ADC
  • Voltage - Supply, Analog: 4.75V ~ 5.25V
  • Base Part Number: ADS8578
  • Voltage - Supply, Digital: 2.3V ~ 5.25V
  • Number of Bits: 14
  • Series: -
  • Package / Case: 64-LQFP
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 64-LQFP (10x10)
  • Number of Inputs: 8
  • Ratio - S/H:ADC: 0:1
  • Reference Type: External, Internal
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 200k
  • Number of A/D Converters: 8
  • Data Interface: Parallel, Serial
  • Architecture: SAR
  • Input Type: Single Ended
  • Features: Simultaneous Sampling
  • detail: 14 Bit Analog to Digital Converter 8 Input 8 SAR 64-LQFP (10x10)
