LMC6001A MDC Datasheet

LMC6001A MDC

Datasheet specifications

Datasheet's name LMC6001A MDC
File size 87.571 KB
File type pdf
Number of pages 18

Download Datasheet LMC6001A MDC

Download Datasheet

Other documentations

Signal e-Book: OP Amp Design Topics 37 pages

LMC6001A MDC 18 pages

LMC6044 24 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LMC6001A MDC
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: -
  • Output Current: 34mA
  • Number of Circuits: 1
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 0.01pA
  • Gain Bandwidth Product(GBP): 1.3MHz
  • Package: -
  • Manufacturer: Texas Instruments
  • Series: -
  • Package / Case: Die
  • Current - Supply: 550µA
  • Voltage - Input Offset: 350µV
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Slew Rate: 1.5V/µs
  • Voltage - Supply, Single/Dual (±): 4.5V ~ 15.5V, ±2.25V ~ 7.75V
  • Gain Bandwidth Product: 1.3MHz
  • Amplifier Type: General Purpose
  • Current - Output / Channel: 34mA
  • Packaging: Tube
  • Base Part Number: LMC6001
  • Current - Input Bias: 0.01pA
  • Output Type: Rail-to-Rail
  • Supplier Device Package: Diesale
  • detail: General Purpose Amplifier 1 Circuit Rail-to-Rail Diesale
