S4MF06607BSPZQQ1 دیتاشیت

S4MF06607BSPZQQ1

مشخصات دیتاشیت

نام دیتاشیت S4MF06607BSPZQQ1
حجم فایل 84.389 کیلوبایت
نوع فایل pdf
تعداد صفحات 65

مشاهده دیتاشیت S4MF06607BSPZQQ1

دانلود دیتاشیت

سایر مستندات

TMS470MF06607 65 pages

مشخصات فنی

  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-M3
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: -
  • Watchdog: Yes
  • ADC (Bit): 10bit
  • DAC (Bit): -
  • Datasheet: Texas Instruments S4MF06607BSPZQQ1
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 80MHz
  • GPIO Ports Number: 49
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: -
  • Program Storage Size: 640KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 1.4V~3.6V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+125°C
  • Secure Digital Input and Output: -
  • Package: LQFP-100
  • Manufacturer: Texas Instruments
  • Peripherals: POR, WDT
  • Voltage - Supply (Vcc/Vdd): 1.4V ~ 3.6V
  • Base Part Number: TMS470
  • Speed: 80MHz
  • Package / Case: 100-LQFP
  • EEPROM Size: -
  • Supplier Device Package: 100-LQFP (14x14)
  • Series: Automotive, AEC-Q100, Hercules™ TMS470M ARM® Cortex®-M3
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Number of I/O: 49
  • Oscillator Type: External
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Core Size: 16/32-Bit
  • Connectivity: CANbus, LINbus, MibSPI, SCI, UART/USART
  • Program Memory Size: 640KB (640K x 8)
  • Core Processor: ARM® Cortex®-M3
  • Packaging: Tray
  • Data Converters: A/D 16x10b
  • detail: ARM® Cortex®-M3 Automotive, AEC-Q100, Hercules™ TMS470M ARM® Cortex®-M3 Microcontroller IC 16/32-Bit 80MHz 640KB (640K x 8) FLASH 100-LQFP (14x14)
