دیتاشیت ADS8343E/2K5

ADS8343

مشخصات دیتاشیت

نام دیتاشیت ADS8343
حجم فایل 1264.154 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت ADS8343

ADS8343 Datasheet

مشخصات

  • Configuration: S/H-ADC
  • Voltage - Supply, Analog: 2.7V ~ 3.6V, 5V
  • Base Part Number: ADS8343
  • Operating Temperature: -40°C ~ 85°C
  • Voltage - Supply, Digital: 2.7V ~ 3.6V, 5V
  • Number of Bits: 16
  • Series: -
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Packaging: Tape & Reel (TR)
  • Supplier Device Package: 16-SSOP
  • Number of Inputs: 2, 4
  • Ratio - S/H:ADC: 1:1
  • Reference Type: External
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 100k
  • Manufacturer: Texas Instruments
  • Number of A/D Converters: 1
  • Data Interface: SPI
  • Architecture: SAR
  • Input Type: Differential, Single Ended
  • Features: -
  • detail: 16 Bit Analog to Digital Converter 2, 4 Input 1 SAR 16-SSOP
