DAC8568IAPWR دیتاشیت

DAC8568IAPWR

مشخصات دیتاشیت

نام دیتاشیت DAC8568IAPWR
حجم فایل 123.404 کیلوبایت
نوع فایل pdf
تعداد صفحات 68

دانلود دیتاشیت DAC8568IAPWR

دانلود دیتاشیت

سایر مستندات

Analog Signal Chain Guide 11 pages

DAC7568,8168,8568 68 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Texas Instruments DAC8568IAPWR
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 10us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±4LSB;±0.2LSB
  • Operating Temperature: -40°C~+125°C
  • Package: TSSOP-16
  • Manufacturer: Texas Instruments
  • Data Interface: SPI, DSP
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Reference Type: External, Internal
  • Supplier Device Package: 16-TSSOP
  • Number of D/A Converters: 8
  • Part Status: Active
  • Number of Bits: 16
  • Architecture: String DAC
  • Series: -
  • Base Part Number: DAC8568
  • Mounting Type: Surface Mount
  • Differential Output: No
  • INL/DNL (LSB): ±4, ±0.2
  • Packaging: Tube
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • detail: 16 Bit Digital to Analog Converter 8 16-TSSOP
