THS1206IDAR دیتاشیت

THS1206IDAR

مشخصات دیتاشیت

نام دیتاشیت THS1206IDAR
حجم فایل 108.192 کیلوبایت
نوع فایل pdf
تعداد صفحات 44

مشاهده دیتاشیت THS1206IDAR

دانلود دیتاشیت

سایر مستندات

THS1206 43 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments THS1206IDAR
  • Package: TSSOP-32-6.1mm
  • Manufacturer: Texas Instruments
  • Configuration: S/H-MUX-ADC
  • Voltage - Supply, Analog: 5V
  • Base Part Number: THS120
  • Operating Temperature: -40°C ~ 85°C
  • Voltage - Supply, Digital: 3V ~ 5.25V
  • Number of Bits: 12
  • Series: -
  • Package / Case: 32-TSSOP (0.240", 6.10mm Width)
  • Packaging: Tape & Reel (TR)
  • Supplier Device Package: 32-TSSOP
  • Number of Inputs: 2, 4
  • Ratio - S/H:ADC: 4:1
  • Reference Type: External, Internal
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 6M
  • Number of A/D Converters: 1
  • Data Interface: Parallel
  • Architecture: Pipelined
  • Input Type: Differential, Single Ended
  • Features: Simultaneous Sampling
  • detail: 12 Bit Analog to Digital Converter 2, 4 Input 1 Pipelined 32-TSSOP
