ADCMP391ARZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADCMP391ARZ
|
|
حجم فایل
|
65.755
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
Analog Devices ADCMP393ARUZ-RL7
-
Output Type:
轨到轨
-
Supply Voltage:
2.3V~5.5V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
0.03uA
-
Input Offset Voltage (Vos):
2.5mV
-
Input Hysteresis Voltage (Vhys):
4mV
-
Common Mode Rejection Ratio (CMRR):
74dB
-
Package:
TSSOP-14
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Type:
General Purpose
-
Voltage - Supply, Single/Dual (±):
2.3V ~ 5.5V
-
Voltage - Input Offset (Max):
2.5mV
-
Current - Input Bias (Max):
30nA
-
Current - Output (Typ):
-
-
Current - Quiescent (Max):
36.8µA
-
CMRR, PSRR (Typ):
74dB CMRR, 80dB PSRR
-
Propagation Delay (Max):
4.2µs
-
Hysteresis:
4mV
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-TSSOP
-
Base Part Number:
ADCMP393
-
detail:
Comparator General Purpose Rail-to-Rail 14-TSSOP
