ADM7160 Datasheet دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADM7160 Datasheet	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: Analog Devices Inc.
Series: -
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Output Configuration: Positive
Output Type: Fixed
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 1.8V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.23V @ 200mA
Current - Output: 200mA
Current - Quiescent (Iq): 20µA
Current - Supply (Max): 350µA
PSRR: 54dB ~ 43dB (100kHz ~ 1MHz)
Control Features: Enable
Protection Features: Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 6-UDFN Exposed Pad, CSP
Supplier Device Package: 6-LFCSP-UD (2x2)
Base Part Number: ADM7160
detail: Linear Voltage Regulator IC 1 Output 200mA 6-LFCSP-UD (2x2)
