ADP7118ARDZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADP7118ARDZ
|
|
حجم فایل
|
103.41
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
23
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices ADP7118AUJZ-4.5-R7
-
Output Current:
200mA
-
Output Voltage:
4.5V
-
Dropout Voltage:
0.42V@(200mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
20V
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Quiescent Current (Ground Current):
140uA
-
Package:
TSOT-23-5
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
20V
-
Voltage - Output (Min/Fixed):
4.5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.42V @ 200mA
-
Current - Output:
200mA
-
Current - Quiescent (Iq):
140µA
-
Current - Supply (Max):
320µA
-
PSRR:
88dB ~ 50dB (10kHz ~ 1MHz)
-
Control Features:
Enable, Soft Start
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Supplier Device Package:
5-TSOT
-
Base Part Number:
ADP7118
-
detail:
Linear Voltage Regulator IC 1 Output 200mA 5-TSOT
