دیتاشیت ADP5302ACPZ-3-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP5302 Datasheet |
|---|---|
| حجم فایل | 554.86 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت ADP5302 Datasheet |
ADP5302 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Programmable
- Number of Outputs: 1
- Voltage - Input (Min): 2.15V
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): 0.8V
- Voltage - Output (Max): 5V
- Current - Output: 50mA, 500mA
- Frequency - Switching: 2MHz
- Synchronous Rectifier: Yes
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 10-VFDFN Exposed Pad, CSP
- Supplier Device Package: 10-LFCSP-WD (3x3)
- detail: Buck Switching Regulator IC Positive Programmable 0.8V 1 Output 50mA, 500mA 10-VFDFN Exposed Pad, CSP
