ADP2230ACPZ-1218R7 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADP2230ACPZ-1218R7	دانلود دیتاشیت

ADP2230 18 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices ADP2230ACPZ-1218R7
Output Type: Fixed
Input Voltage: 2.3V~6.5V
Output Voltage: 1.2V;1.8V
Number of Outputs: 2
Switching Frequency: 2MHz
Output Current (Max): 800mA
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: LFCSP-10
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Output Configuration: Positive
Voltage - Input (Min): 2.3V
Voltage - Input (Max): 6.5V
Voltage - Output (Min/Fixed): 1.2V, 1.8V
Voltage - Output (Max): -
Current - Output: 800mA
Frequency - Switching: 2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 10-VFDFN Exposed Pad, CSP
Supplier Device Package: 10-LFCSP-WD (3x3)
Base Part Number: ADP2230
detail: Buck Switching Regulator IC Positive Fixed 1.2V, 1.8V 2 Output 800mA 10-VFDFN Exposed Pad, CSP
