ADP5042 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADP5042 |
|---|---|
| حجم فایل | 1590.451 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت ADP5042 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADP5042ACPZ-1-R7 30 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Topology: Step-down
- Datasheet: Analog Devices ADP5042ACPZ-2-R7
- Input Voltage: 1.7V~5.5V
- Number of Outputs: 3
- Switching Frequency: 3MHz
- Operating Temperature: -40°C~+125°C
- Package: LFCSP-20
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Frequency - Switching: 3MHz
- Voltage/Current - Output 1: 1.5V, 800mA
- Voltage/Current - Output 2: 1.8V, 300mA
- Voltage/Current - Output 3: 3.3V, 300mA
- w/LED Driver: No
- w/Supervisor: Yes
- w/Sequencer: Yes
- Voltage - Supply: 1.7V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 20-WFQFN Exposed Pad, CSP
- Supplier Device Package: 20-LFCSP-WQ (4x4)
- Base Part Number: ADP5042
- detail: PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 3MHz 20-LFCSP-WQ (4x4)
