دیتاشیت ADUM1440ARQZ-RL7

مشخصات دیتاشیت

دانلود دیتاشیت ADUM144x Datasheet	ADUM144x Datasheet Datasheet

Manufacturer: Analog Devices Inc.
Series: iCoupler®
Packaging: Tape & Reel (TR)
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: No
Number of Channels: 4
Inputs - Side 1/Side 2: 4/0
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs
Data Rate: 2Mbps
Propagation Delay tpLH / tpHL (Max): 180ns, 180ns
Pulse Width Distortion (Max): 8ns
Rise / Fall Time (Typ): 2ns, 2ns
Voltage - Supply: 2.25V ~ 3.6V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 16-SSOP (0.154", 3.90mm Width)
Supplier Device Package: 16-QSOP
Base Part Number: ADUM1440
detail: General Purpose Digital Isolator 2500Vrms 4 Channel 2Mbps 25kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
