دیتاشیت ADP1720TRMZ-EP-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP1720-EP |
|---|---|
| حجم فایل | 920.037 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت ADP1720-EP |
ADP1720-EP Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices ADP1720TRMZ-EP-R7
- Output Type: Adjustable
- Output Current: 50mA
- Output Voltage: 1.225V~5V
- Dropout Voltage: 0.48V@(50mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 28V
- Operating Temperature: -55°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Package: MSOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 28V
- Voltage - Output (Min/Fixed): 1.225V
- Voltage - Output (Max): 5V
- Voltage Dropout (Max): 0.48V @ 50mA
- Current - Output: 50mA
- Current - Quiescent (Iq): 80µA
- Current - Supply (Max): 2.115mA
- PSRR: 90dB ~ 50dB (120Hz ~ 10kHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 8-MSOP
- Base Part Number: ADP1720
- detail: Linear Voltage Regulator IC 1 Output 50mA 8-MSOP
