ADF7025BCPZ-RL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADF7025BCPZ-RL
|
|
حجم فایل
|
78.83
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
41
|
مشخصات فنی
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Transceiver ICs
-
Datasheet:
Analog Devices ADF7025BCPZ-RL
-
Package:
LFCSP-48-EP(7x7)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Type:
TxRx Only
-
RF Family/Standard:
General ISM < 1GHz
-
Protocol:
-
-
Modulation:
FSK
-
Frequency:
431MHz ~ 464MHz, 862MHz ~ 870MHz, 902MHz ~ 928MHz
-
Data Rate (Max):
384kbps
-
Power - Output:
13dBm (Max)
-
Sensitivity:
-104.2dBm
-
Memory Size:
-
-
Serial Interfaces:
SPI
-
Voltage - Supply:
2.3V ~ 3.6V
-
Current - Receiving:
19mA ~ 21mA
-
Current - Transmitting:
14.6mA ~ 28mA
-
Operating Temperature:
-40°C ~ 85°C
-
Mounting Type:
Surface Mount
-
Package / Case:
48-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
48-LFCSP-WQ (7x7)
-
Base Part Number:
ADF7025
-
detail:
IC RF TxRx Only General ISM < 1GHz 431MHz ~ 464MHz, 862MHz ~ 870MHz, 902MHz ~ 928MHz 48-WFQFN Exposed Pad, CSP
