دیتاشیت ADUM1286WARZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت |
ADuM1280/1/5/6
|
| حجم فایل |
397.493
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
18
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
Automotive
-
Packaging:
Tube
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
General Purpose
-
Isolated Power:
No
-
Number of Channels:
2
-
Inputs - Side 1/Side 2:
1/1
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
3000Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Data Rate:
1Mbps
-
Propagation Delay tpLH / tpHL (Max):
50ns, 50ns
-
Pulse Width Distortion (Max):
10ns
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Voltage - Supply:
3V ~ 5.5V
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
ADUM1286
-
detail:
General Purpose Digital Isolator 3000Vrms 2 Channel 1Mbps 25kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
