دیتاشیت ADF7901BRUZ-RL

ADF7901

مشخصات دیتاشیت

نام دیتاشیت ADF7901
حجم فایل 168.828 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADF7901

ADF7901 Datasheet

مشخصات

  • RoHS: true
  • Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
  • Datasheet: Analog Devices ADF7901BRUZ-RL
  • Package: TSSOP-24
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Frequency: 369.5 ~ 395.9MHz
  • Applications: ISM
  • Modulation or Protocol: ASK, FSK, OOK
  • Data Rate (Max): 50kbps
  • Power - Output: 7dBm ~ 12dBm
  • Current - Transmitting: 26mA
  • Data Interface: PCB, Surface Mount
  • Antenna Connector: PCB, Surface Mount
  • Memory Size: -
  • Features: -
  • Voltage - Supply: 3V
  • Operating Temperature: 0°C ~ 50°C
  • Mounting Type: Surface Mount
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 24-TSSOP
  • Base Part Number: ADF7901
  • detail: RF Transmitter ASK, FSK, OOK 369.5 ~ 395.9MHz 7dBm ~ 12dBm 50kbps PCB, Surface Mount Antenna 24-TSSOP (0.173", 4.40mm Width)
