DAC7664YT دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | DAC7664YT |
|---|---|
| حجم فایل | 89.79 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت DAC7664YT |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog Signal Chain Guide 11 pages
DAC7664 Datasheet 33 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Texas Instruments DAC7664YT
- Interface: Parallel
- Resolution: 16Bit
- Output Type: Voltage-缓冲
- Settling Time: 15us
- Supply Voltage: 5V
- Integral nonlinearity: ±3LSB;±2LSB
- Operating Temperature: -40°C~+85°C
- Package: LQFP-64(10x10)
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Supply, Digital: 5V
- Voltage - Supply, Analog: ±5V
- INL/DNL (LSB): ±3, ±2
- Supplier Device Package: 64-LQFP (10x10)
- Package / Case: 64-LQFP
- Number of Bits: 16
- Differential Output: No
- Part Status: Active
- Reference Type: Internal
- Mounting Type: Surface Mount
- Architecture: R-2R
- Number of D/A Converters: 4
- Packaging: Tape & Reel (TR)
- Base Part Number: DAC7664
- Data Interface: Parallel
- detail: 16 Bit Digital to Analog Converter 4 64-LQFP (10x10)
