ADL5505ACBZ-P7 Datasheet
Datasheet specifications
| Datasheet's name | ADL5505 |
|---|---|
| File size | 1239.662 KB |
| File type | |
| Number of pages | 20 |
Download Datasheet ADL5505 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: TruPwr™
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Frequency: 450MHz ~ 6GHz
- RF Type: LTE, WiMax
- Input Range: -22dBm ~ 15dBm
- Accuracy: ±0.25dB
- Voltage - Supply: 2.5V ~ 3.3V
- Current - Supply: 1.8mA
- Mounting Type: Surface Mount
- Package / Case: 4-WFBGA, WLCSP
- Supplier Device Package: 4-WLCSP
- Base Part Number: ADL5505
- detail: RF Detector IC LTE, WiMax 450MHz ~ 6GHz -22dBm ~ 15dBm ±0.25dB 4-WFBGA, WLCSP
