دیتاشیت ADM7155ARDZ-02-R7

ADM7155

مشخصات دیتاشیت

نام دیتاشیت ADM7155
حجم فایل 717.667 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت ADM7155

ADM7155 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 2.4V
  • Voltage Dropout (Max): 0.21V @ 600mA
  • Current - Output: 600mA
  • Current - Quiescent (Iq): 7mA
  • Current - Supply (Max): 10mA
  • PSRR: 94dB ~ 61dB (1kHz ~ 1MHz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC
  • Base Part Number: ADM7155
  • detail: Linear Voltage Regulator IC 1 Output 600mA 8-SOIC
