دیتاشیت ADP7157ARDZ-01-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP7157 |
|---|---|
| حجم فایل | 1031.361 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت ADP7157 |
ADP7157 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices ADP7157ARDZ-01-R7
- Output Type: Adjustable
- Output Current: 1.2A
- Output Voltage: 1.2V~1.8V
- Dropout Voltage: 0.17V@(1.2A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 8mA
- Package: SOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 1.8V
- Voltage Dropout (Max): 0.17V @ 1.2A
- Current - Output: 1.2A
- Current - Quiescent (Iq): 8mA
- Current - Supply (Max): 12mA
- PSRR: 70dB ~ 52dB (1kHz ~ 1MHz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Supplier Device Package: 8-SOIC-EP
- Base Part Number: ADP7157
- detail: Linear Voltage Regulator IC 1 Output 1.2A 8-SOIC-EP
