ADGS1212BCPZ-RL7 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADGS1212BCPZ-RL7	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADGS1212BCPZ-RL7
Turn-on time: 490ns
Turn-off time: 225ns
Supply Voltage: 5V~16.5V
Switch Circuit: SPST(SPST)-Normal Open
Number of Channels: 4
On-State Resistance (Max): 260Ω;625Ω
Package: LFCSP-24
Manufacturer: Analog Devices
Series: -
Packaging: Tape & Reel (TR)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 4
Channel-to-Channel Matching (ΔRon): 11Ohm, 27Ohm
Voltage - Supply, Single (V+): 5V ~ 16.5V
Voltage - Supply, Dual (V±): ±4.5V ~ 16.5V
Switch Time (Ton, Toff) (Max): 490ns, 225ns
-3db Bandwidth: 1GHz
Charge Injection: 1pC
Channel Capacitance (CS(off), CD(off)): 1.4pF, 1.5pF
Current - Leakage (IS(off)) (Max): 1nA
Crosstalk: -110dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 24-WFQFN Exposed Pad, CSP
Supplier Device Package: 24-LFCSP-WQ (4x4)
Base Part Number: ADGS1212
detail: 4 Circuit IC Switch 1:1 260Ohm, 625Ohm 24-LFCSP-WQ (4x4)
