ADP5024 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADP5024 |
|---|---|
| حجم فایل | 764.345 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 28 |
دانلود دیتاشیت ADP5024 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADP5024ACPZ-1-R7 28 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Topology: Step-down
- Datasheet: Analog Devices ADP5024ACPZ-2-R7
- Input Voltage: 1.7V~5.5V
- Number of Outputs: 3
- Switching Frequency: 3MHz
- Operating Temperature: -40°C~+125°C
- Package: LFCSP-24
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Frequency - Switching: 3MHz
- Voltage/Current - Output 1: 0.8V ~ 3.8V, 1.2A
- Voltage/Current - Output 2: 0.8V ~ 3.8V, 1.2A
- Voltage/Current - Output 3: 0.8V ~ 5.2V, 300mA
- w/LED Driver: No
- w/Supervisor: No
- w/Sequencer: No
- Voltage - Supply: 1.7V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 24-WFQFN Exposed Pad, CSP
- Supplier Device Package: 24-LFCSP-WQ (4x4)
- Base Part Number: ADP5024
- detail: PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (2), Linear (LDO) (1) 3MHz 24-LFCSP-WQ (4x4)
