دیتاشیت ADM7151ARDZ-02-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADM7151 |
|---|---|
| حجم فایل | 1169.758 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت ADM7151 |
ADM7151 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices ADM7151ARDZ-02-R7
- Output Type: Adjustable
- Output Current: 800mA
- Output Voltage: 1.5V~4V
- Dropout Voltage: 1.2V@(800mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 16V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 7mA
- Package: SOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 1.5V
- Voltage - Output (Max): 4V
- Voltage Dropout (Max): 1.2V @ 800mA
- Current - Output: 800mA
- Current - Quiescent (Iq): 7mA
- Current - Supply (Max): 12mA
- PSRR: 94dB ~ 50dB (1kHz ~ 1MHz)
- Control Features: Enable
- Protection Features: Over Temperature, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
- Supplier Device Package: 8-SOIC-EP
- Base Part Number: ADM7151
- detail: Linear Voltage Regulator IC 1 Output 800mA 8-SOIC-EP
