TMS320DM8148SCYE1 دیتاشیت

TMS320DM8148SCYE1

مشخصات دیتاشیت

نام دیتاشیت TMS320DM8148SCYE1
حجم فایل 125.552 کیلوبایت
نوع فایل pdf
تعداد صفحات 376

دانلود دیتاشیت TMS320DM8148SCYE1

دانلود دیتاشیت

سایر مستندات

TMS320DM814x Datasheet 376 pages

TMS320DM814x Errata 66 pages

TMS320DM8127, 814x Reference Manual 3910 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: -
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: -
  • Watchdog: -
  • ADC (Bit): -
  • DAC (Bit): -
  • Datasheet: Texas Instruments TMS320DM8148SCYE1
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 1GHz
  • GPIO Ports Number: -
  • Low-Voltage Detect: -
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: -
  • Peripheral/Function: Ethernet protocol stack;SDIO
  • Program Memory Type: -
  • Direct Memory Access: -
  • Program Storage Size: -
  • Universal Serial Bus: Yes
  • communication protocol: 以太网协议
  • Operating Voltage Range: -
  • Infrared Data Association: -
  • Operating Temperature Range: 0°C~+90°C
  • Secure Digital Input and Output: Yes
  • Package: BGA-684
  • Manufacturer: Texas Instruments
  • Series: DM81x Video SOC, DaVinci™
  • Type: Digital Media System-on-Chip (DMSoC)
  • Package / Case: 684-BFBGA, FCBGA
  • Supplier Device Package: 684-FCBGA (23x23)
  • Voltage - I/O: 1.5V, 1.8V, 3.3V
  • Part Status: Active
  • Mounting Type: Surface Mount
  • On-Chip RAM: 1.08MB
  • Clock Rate: 700MHz DSP, 1GHz ARM®
  • Operating Temperature: 0°C ~ 90°C (TJ)
  • Non-Volatile Memory: ROM (48kB)
  • Voltage - Core: 1.1V, 1.2V, 1.35V
  • Packaging: Tray
  • Base Part Number: TMS320
  • Interface: CAN, Ethernet, I²C, McASP, McBSP, MMC/SD/SDIO, SATA, SPI, UART, USB
  • detail: IC DGTL MEDIA PROCESSR 684FCBGA
