دیتاشیت AD5441BRMZ-REEL7

AD5441

مشخصات دیتاشیت

نام دیتاشیت AD5441
حجم فایل 402.499 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت AD5441

AD5441 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5441BRMZ-REEL7
  • Interface: serial
  • Resolution: 12Bit
  • Output Type: Current-非缓冲
  • Settling Time: 5us
  • Supply Voltage: 2.5V~5.5V
  • Integral nonlinearity: ±0.5LSB
  • Operating Temperature: -40°C~+125°C
  • Package: MSOP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: Serial
  • Reference Type: External
  • Voltage - Supply, Analog: 2.5V ~ 5.5V
  • Voltage - Supply, Digital: 2.5V ~ 5.5V
  • INL/DNL (LSB): ±0.5 (Max), ±0.5 (Max)
  • Architecture: R-2R
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 8-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: AD5441
  • detail: 12 Bit Digital to Analog Converter 1 8-MSOP
