ADGS5412BCPZ دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADGS5412BCPZ	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADGS5412BCPZ
Package: LFCSP-24
Manufacturer: Analog Devices
Series: -
Packaging: Tray
Part Status: Active
Switch Circuit: SPST - NO
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 4
On-State Resistance (Max): 10Ohm
Channel-to-Channel Matching (ΔRon): 350mOhm
Voltage - Supply, Single (V+): 9V ~ 40V
Voltage - Supply, Dual (V±): ±9V ~ 22V
Switch Time (Ton, Toff) (Max): 530ns, 230ns
-3db Bandwidth: 160MHz
Charge Injection: 310pC
Channel Capacitance (CS(off), CD(off)): 17pF, 17pF
Current - Leakage (IS(off)) (Max): 250pA
Crosstalk: -70dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 24-VFQFN Exposed Pad
Supplier Device Package: 24-LFCSP (4x4)
Base Part Number: ADGS5412
detail: 4 Circuit IC Switch 1:1 10Ohm 24-LFCSP (4x4)
