ADS5522IPAP دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADS5522IPAP	دانلود دیتاشیت

ADS5522 32 pages

RoHS: true
Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
Datasheet: Texas Instruments ADS5522IPAP
Interface: Parallel
resolution: 12Bit
Supply Voltage: 3V~3.6V
differential input: Yes
number of channels: 1
sampling frequency: 80MHz
Operating Temperature: -40°C~+85°C
Package: HTQFP-64(10x10)
Manufacturer: Texas Instruments
Configuration: S/H-ADC
Voltage - Supply, Analog: 3V ~ 3.6V
Base Part Number: ADS5522
Voltage - Supply, Digital: 3V ~ 3.6V
Number of Bits: 12
Series: -
Package / Case: 64-PowerTQFP
Packaging: Tray
Supplier Device Package: 64-HTQFP (10x10)
Number of Inputs: 1
Ratio - S/H:ADC: 1:1
Reference Type: Internal
Mounting Type: Surface Mount
Part Status: Active
Sampling Rate (Per Second): 80M
Number of A/D Converters: 1
Data Interface: Parallel
Architecture: Pipelined
Input Type: Differential
Features: -
detail: 12 Bit Analog to Digital Converter 1 Input 1 Pipelined 64-HTQFP (10x10)
