- دیتاشیت ADG5436F Datasheet
ADG5436F Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADG5436F Datasheet |
|---|---|
| حجم فایل | 668.75 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت ADG5436F Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
ADG5436FBRUZ 30 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Analog Devices ADG5436FBRUZ-RL7
- Turn-on time: 535ns
- Turn-off time: 205ns
- Supply Voltage: 8V~44V
- Switch Circuit: SPDT(SPDT)
- Number of Channels: 2
- On-State Resistance (Max): 11.5Ω
- Package: TSSOP-16
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Multiplexer/Demultiplexer Circuit: 2:1
- Number of Circuits: 2
- Channel-to-Channel Matching (ΔRon): 150mOhm
- Voltage - Supply, Single (V+): 8V ~ 44V
- Voltage - Supply, Dual (V±): ±5V ~ 22V
- Switch Time (Ton, Toff) (Max): 535ns, 205ns
- -3db Bandwidth: 171MHz
- Charge Injection: -737pC
- Channel Capacitance (CS(off), CD(off)): 11pF, 23pF
- Current - Leakage (IS(off)) (Max): 500pA
- Crosstalk: -73dB @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 16-TSSOP
- Base Part Number: ADG5436
- detail: 2 Circuit IC Switch 2:1 11.5Ohm 16-TSSOP
